Name: 12um Electrolytic Copper Foil
Brand: Beijing Silk Road Enterprise Management Services Co.,LTD
Availability: InStock

Home Products Electrolytic Copper Foil

12um Electrolytic Copper Foil

Product Details:

Place of Origin:	China
Brand Name:	OEM
Certification:	ISO / SGS / RoHS

Payment & Shipping Terms:

Minimum Order Quantity:	50kg
Price:	Negotiable
Packaging Details:	Exporting Wooden Case
Delivery Time:	10 - 15 Days
Payment Terms:	L/C, T/T
Supply Ability:	550T Per Month

Contact Now

Detailed Product Description

Application:	Battery	Width:	Customized
Material:	Brass	Grade:	Pure Copper
Cu (Min):	>=99.8	Alloy Or Not:	Non-alloy
Wettability:	≥32mN/m	Color:	Red
Shape:	Customised	Type:	Flat
Highlight:	9um Electrolytic Copper Foil , 12um Electrolytic Copper Foil , 7um Electrolytic Copper Foil

Rolled Electrolytic Copper Foil

Product Description

Copper strip is made of electrolytic copper and it goes through the processes of ingot, hot rolling, cold rolling, heat treatment, surface cleaning, cutting, finishing, and then packing. The material has excellent thermal and electrical conduction, flexible ductility and good corrosion resistance performance. It has been widely used in electrical, automotive, communications, hardware, decoration and other industries.

Features:

1. Double -side treated copper foil with high binding force to laminate

2. Excellent etchability.

3. Direct multi-layer laminate

4. the treated foil is pink

The specification of Copper foil

Item		DB44/837-2010 standard				Q/HZY001-2012 standard
Item		Double side polished			Single side polished	Double side polished				Single side polished
Standard Thick	um	8	9	12	9	7	8	9	12	8	9
Basic weight	g/m2	70-75	85-90	100-105	85-90	62-65	70-75	85-90	100-105	70-75	85-95
Test thickness	um	/	/	/	/	≤8	≤9	≤10	≤13	≤10	≤11
Cu	%	≥99.8	≥99.8	≥99.8	≥99.8	≥99.8	≥99.8	≥99.8	≥99.8	≥99.8	≥99.8
TS	Room	≥294	≥294	≥294	≥245	≥294	≥294	≥294	≥294	≥245	≥245
TS	180℃	≥196	≥196	≥196	≥147	≥196	≥196	≥196	≥196	≥147	≥147
Ductility	Room	≥5	≥5	≥5	≥2.5	≥5	≥5	≥5	≥5	≥2.5	≥2.5
Ductility	180℃	≥3	≥3	≥3	≥2	≥3	≥3	≥3	≥3	≥2	≥2
surface roughness	Polished side	≤3	≤3	≤3	≤3	≤3	≤3	≤3	≤3	≤3	≤3
surface roughness	Coarse side	≤0.3	≤0.3	≤0.3	≤0.5	≤0.3	≤0.3	≤0.3	≤0.3	≤0.5	≤0.5
wettability	mN/m	≥32	≥32	≥32	≥32	≥32	≥32	≥32	≥32	≥32	≥32
high temperature oxidation resistance	160℃/10 min copper foil surface should be no oxidation discoloration					180℃/10 min copper foil surface should be no oxidation discoloration

12um Electrolytic Copper Foil 0
